4,4'-oxydibenzenesulfonyl Hydrazide /OBSH Foaming Agent

Azodicarbonamide/AC Foaming Agent Model Features

Model	Color	Decomposition temperature	Gas volume	Fineness	Application
OBSH	White	160±5℃	120±5ml/g	4-6µm	Suitable for all kinds of rubber and plastic products, can improve density and whiteness of the final products. Widely used in EPDM sealing strips.
OBSH-1	White	160±5℃	115±5ml/g	4-6µm

Foaming Agent Selection Guide

Above is just part of our general grades, we also can supply modified products and blowing agent masterbatch.
If you want to know further information or more grades, please contact sales01@zjshuntaitech.com

For More Industry Solutions, Your Consultation Is Welcome

Learn About Our Solutions

Physical Properties

Appearance

White crystalline powder

Melting Point

160–161°C

Density

1.52 g/cm³

Solubility

Slightly soluble in hot water and ethanol, insoluble in cold water and most organic solvents.

Synthesis Methods

Chlorosulfonation Route

Start with diphenyl ether, react with chlorosulfonic acid to produce 4,4'-oxydibenzene sulfonyl chloride, then react with hydrazine hydrate to yield 4,4'-oxydibenzene sulfonyl hydrazide.

Sulfonation and Reaction with Phosphorus Oxychloride

Treat diphenyl ether with concentrated sulfuric acid for sulfonation, react with phosphorus oxychloride to form 4,4'-oxydibenzene sulfonyl chloride, and subsequently react with hydrazine hydrate and aqueous ammonia to produce the target compound.

Chemical Properties

4,4'-Oxydibenzene Sulfonyl Hydrazide exhibits chemical stability but can undergo reactions under specific conditions. It contains sulfonyl hydrazide functional groups, making it suitable for various organic synthesis reactions.
This compound also demonstrates good thermal stability and chemical inertness and is suitable for various industrial applications.

Select Our Foaming Agent Products

Zhejiang Shuntai Rubber and Plastic Technology CO., LTD. is a technology company specializing in producing and selling foaming agent. The Company is located in Quzhou, Zhejiang Province and was founded in 2008. Thefactory covers an area of 12098 square meters. It is divided into ultra-fine crushing workshop, mixing workshop, rubber mixing workshop, laboratory, low temperature finished workshop, raw materials warehouse and so on.

Chat Now

Main Areas Of Application

Rubber Industry

Used as a blowing agent, 4,4'-oxydibenzene sulfonyl hydrazide enhances the elasticity, abrasion resistance, and aging performance of rubber products while reducing density for lightweight applications. It is commonly utilized in manufacturing tires, shoe soles, sealing strips, soundproofing materials, and similar products.

Plastics Industry

As a blowing agent, it improves the lightweight, thermal insulation, and acoustic properties of plastic products. Applications include foam plastics, insulation materials, and soundproofing boards, often used in elastomers and thermoplastics for normal-pressure or expanded foaming processes.

Other Industrial Applications

In addition to the rubber and plastics industries, this compound is employed in:
Chemical Industry: As a raw material for synthesizing other compounds.
Construction Materials: For producing lightweight, high-strength building materials.
Textile Industry: For creating insulating and soundproofing textile materials.

Potential Applications

Advancements in technology and rising material performance demands are expanding its potential uses:
Environmental Applications: Its non-toxic and biodegradable properties make it a promising component of eco-friendly materials.
New Energy Applications: It may be used in the production of high-performance battery separators and other materials for renewable energy technologies.

Precautions

Although 4,4'-Oxydibenzene Sulfonyl Hydrazide is widely used in many fields, its safety and toxicity issues need to be paid attention to during use. This compound has certain toxicity, is harmful if swallowed, and can cause skin irritation and severe eye irritation. Long-term or repeated contact may cause damage to organs.
Therefore, it is necessary to strictly abide by relevant safety regulations and operating procedures during use to ensure the safety of personnel and the environment.

Safety and Toxicity

Hazards
● Toxic when ingested.
● Causes skin irritation and severe eye irritation.
● Long-term or repeated contact may cause damage to organs.
● The compound is also suspected of causing genetic defects and is extremely toxic to aquatic life with long-lasting effects.
Safety Instructions
● S26: In case of eye contact, rinse thoroughly with water and seek medical advice.
● S37/39: Wear appropriate gloves and eye/face protection.
Risk Phrases
● R11: Highly flammable.
● R44: Risk of explosion when heated in a confined space.
